- Technical Parameter
| Product Attributes | |
|---|---|
| 制造商 | Texas Instruments |
| 产品种类 | 开关控制器 |
| 拓扑结构 | Full-Bridge |
| 输出端数量 | 1 Output |
| 开关频率 | 100 kHz |
| 占空比 - 最大 | 97 % |
| 输入电压 | 8 V to 17 V |
| 输出电压 | 5 V |
| 输出电流 | 200 mA |
| 最小工作温度 | - 40 C |
| 最大工作温度 | + 125 C |
| 安装风格 | SMD/SMT |
| 封装 / 箱体 | TSSOP-24 |
| 封装 | Reel |
| 封装 | Cut Tape |
| 封装 | MouseReel |
| 商标 | Texas Instruments |
| 描述/功能 | Phase-shifted full-bridge controller |
| 下降时间 | 7 ns |
| 绝缘 | Non-Isolated |
| 湿度敏感性 | Yes |
| 工作电源电流 | 5 mA |
| 工作电源电压 | 8 V to 17 V |
| 产品 | Full-Bridge Controllers |
| 产品类型 | Switching Controllers |
| 上升时间 | 9 ns |
| 系列 | UCC28951 |
| 关闭 | Shutdown |
| 工厂包装数量 | 2000 |
| 子类别 | PMIC - Power Management ICs |
| 单位重量 | 148.300 mg |
| Datasheet | |
|---|---|
| No Data | |
- Commodity Description
Texas Instruments UCC28951/UCC28951-Q1全桥控制器是基于TI行业标准UCC28950的增强型相移全桥控制器。这些控制器完美兼容替代UCC28950。UCC28951/UCC28951-Q1实现全桥的高级控制以及同步整流器 (SR) 输出级的主动控制。可编程延迟确保ZVS在各种工作条件下运行。这种延迟在负载电流自然调谐二次侧SR的开关延迟时完成。此功能可最大限度地提高系统整体效率。
